MAIN APPLICATION | Food,beverage N Pharmaceutical industry etc,such as transportations of bottles. |
MATERIAL | POM |
MATERIAL | PP |
WORKING LOAD(25°c) | 10500N /M |
WORK TEMP | -40°c to +90°c |
PITCH=15.2 MM | WIDTH=152 MM |
Standard Width W =152. 4*N
mm | 152.4 | 304.8 | 457.2 | 609.6 | 762 | 914.4 | 1066.8 | 1219.2 | 1371.6 | 1524 |
Non standard width, starts from 152.4, with 8.4mm increments
Code | Teeth NO | PD | OD | Bore/mm |
3-900-6-25 | 6 | 54.4 | 53 | 25 |
3-900-9-40*40 | 9 | 79.5 | 81 | 40*40 |
3-900-12-30 | 12 | 105 | 109 | 30 |
3-900-12-40*40 | 40*40 | |||
3-900-13-30 | 18 | 156.6 | 160 | 30 |
3-900-13-40 | 40 | |||
3-900-13-60 | 60 | |||
3-900-18-38.1*38.1 | 38.1*38.1 | |||
3-900-18-40*40 | 40*40 | |||
3-900-13-60*60 | 60*60 |
